Hettich TopLine L Sliding System- 3 Door
Non-returnable
type
Optional
Customize
Choose Quantity :
Product Information
Product Details
Topline L -Loft Version
- Door weight up to 50 kg
- Track Length 3000 mm
- Two track, top-running sliding door system
- Overlay door position
- For wooden or 55 mm wide aluminium frame doors
- Door weight up to 50 kg
- Door height up to 2600 mm
- Door width 550 - 2000 mm
- Door thickness 16-25 mm
- Height adjustment +/- 2 mm
- Top panel thickness max. 22 mm
- Widely opened doors, through offset doors (34 mm offset) / optional: flush doors (0 mm offset)
- Tested to EN 15706, Level 3
Topline L Non-Loft Version
- Two track, top-running sliding door system
- Overlay door position
- For wooden doors
- Door weight up to 50 kg
- Track Length 3000 mm
- Door height up to 2600 mm
- Door width 550-1350 mm
- Door thicknesses 18-50 mm
- Height adjustment +/- 3 mm
- Individually finished running components
- Two opening versions: flush or offset when using projecting handles
- Fast assembly of guide components
- Tested to EN 15706, Level 3
